LED Retrofit Kits
-
Read More
30W LED Retrofit Kits30W LED Retrofit Kits
Product Description
KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
The 5th generation LED retrofit kits are upgraded to a more uniform and unique design with great performance enhancements. The Kits deliver over 125LPW. With best in class “Lumen per Watt Performance” one can expect maximized energy savings, it save up to 80% in electric, and eliminates your lighting maintenance for 10+ year by utilizing the highest quality LED chips, drivers, heat sinks, thermal pad, PCB boards, mounting arms, etc.
Specificaion Summary
Power (W)
30W
30W
30W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
3,767
3,815
3,864
Efficacy (lm/W)
128
128
128
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
4.72″x 4.72″x1.97″
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Qaulity Control
IQC
1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.
IQC
1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
FQC
1. 100% appearance checking
2. 100% lable checking
3. 100% function checking
Latest Nichia Technology chips
1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
Real Mean Well driver
One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.
Sunon Fan Technology
1. Unique design with fan (fans) inside, more uniform structure.
2. Smaller size, almost zero noise.
3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.
New Patented heat sink design
1. Adopting AL6063 material of high structural intensity.
2. Lower profile heat sink design, more slim.
3. Flat outer surface on the heat sink, more elegant.
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation -
Read More
45W LED Retrofit Kits45W LED Retrofit Kits
Product Description
KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
With various mounting brackets, the kits could retrofit a majority of fixtures whether it is a vertical or horizontal installation, eg: street light fixtures, shoebox fixtures, wall pack fixtures, flood light fixtures, canopy fixtures, and high bay fixtures, etc.
Specificaion Summary
Power (W)
45W
45W
45W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
5,700
5,704
5,713
Efficacy (lm/W)
128
128
128
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
4.72"x 4.72"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Qaulity Control
IQC
1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.
IQC
1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
FQC
1. 100% appearance checking
2. 100% lable checking
3. 100% function checking
Mass Production
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation -
Read More
60W LED Retrofit Lights Kit60W LED Retrofit Lights Kit
Product Description
KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
The 5th generation LED retrofit kits are upgraded to a more uniform and unique design with great performance enhancements. The Kits deliver over 125LPW. With best in class “Lumen per Watt Performance” one can expect maximized energy savings, it save up to 80% in electric, and eliminates your lighting maintenance for 10+ year by utilizing the highest quality LED chips, drivers, heat sinks, thermal pad, PCB boards, mounting arms, etc.
Specificaion Summary
Power (W)
60W
60W
60W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
6,613
6,618
6,728
Efficacy (lm/W)
128
128
128
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
4.72"x 4.72"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Mass Production
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation -
Read More
75W LED Lighting Retrofit Kits75W LED Lighting Retrofit Kits
Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Specificaion Summary
Power (W)
75W
75W
75W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
8,964
9,038
9,112
Efficacy (lm/W)
125
126
126
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
6.10"x 5.12"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Latest Nichia Technology chips
1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
Real Mean Well driver
One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.
Sunon Fan Technology
1. Unique design with fan (fans) inside, more uniform structure.
2. Smaller size, almost zero noise.
3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.
New Patented heat sink design
1. Adopting AL6063 material of high structural intensity.
2. Lower profile heat sink design, more slim.
3. Flat outer surface on the heat sink, more elegant.
Mountings
Installation Process
How to install the DLC ETL cETL 75w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation -
Read More
100W High Bay LED Retrofit100W High Bay LED Retrofit
Product Description
KAIWIM generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
The LED retrofit produces 12,412 lumens with a wattage of 100W to replace a 200-300W HID fixture. You keep your fixture and replace the bulb and ballast with LED Head and LED Driver. Simple, quick, fast, economical - and you get to re-use your investment in your paid-for fixtures.
These retrofits have a unique mounting bracket to mount vertically or horizontally inside wall pack, flood light, shoebox, canopy and round high bay fixtures.
Specificaion Summary
Power (W)
100W
100W
100W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
12,412
12,460
12,509
Efficacy (lm/W)
125
126
126
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
6.10"x 5.12"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Installation Process
How to install the DLC ETL cETL 100w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Qaulity Control
IQC
1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.
IQC
1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
FQC
1. 100% appearance checking
2. 100% lable checking
3. 100% function checking
Mass Production
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation -
Read More
120W Shoebox LED Retrofit Kits120W Shoebox LED Retrofit Kits
Product Description
120W Retrofit Kit replaces 300 Watt Metal Halide or High Pressure Sodium in your existing fixture with a simple and easy to perform retrofit process. Up to 125 lumens per watt, depending on the chosen color temperature.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Specificaion Summary
Power (W)
120W
120W
120W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
14,402
14,458
14,469
Efficacy (lm/W)
125
126
126
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
6.10"x 5.12"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Qaulity Control
IQC
1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.
IQC
1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
FQC
1. 100% appearance checking
2. 100% lable checking
3. 100% function checking
Mass Production
Installation Process
How to install the DLC ETL cETL 120w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation -
Read More
150W LED Retrofit Kits150W LED Retrofit Kits
Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Why Use LED Retrofit Kits
LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.
LED Retrofit Kits for Open Air Parking Garage
LED Retrofit Kits for Traditional Wall Pack
Specificaion Summary
Power (W)
150W
150W
150W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
17,516
17,585
17,653
Efficacy (lm/W)
124
125
125
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
7.87"x 5.91"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Mass Production
Application
The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture… -
Read More
200W LED Retrofit Kits200W LED Retrofit Kits
Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Why Use LED Retrofit Kits
LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.
LED Retrofit Kits for Open Air Parking Garage
LED Retrofit Kits for Traditional Wall Pack
Specificaion Summary
Power (W)
200W
200W
200W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
22,415
22,569
22,723
Efficacy (lm/W)
122
123
123
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
7.87"x 5.91"x1.97"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Latest Nichia Technology chips
1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
Real Mean Well driver
One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.
Sunon Fan Technology
1. Unique design with fan (fans) inside, more uniform structure.
2. Smaller size, almost zero noise.
3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.
New Patented heat sink design
1. Adopting AL6063 material of high structural intensity.
2. Lower profile heat sink design, more slim.
3. Flat outer surface on the heat sink, more elegant.
Installation Process
How to install the DLC ETL cETL 200w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Application
The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture… -
Read More
280W LED Retrofit Kits280W LED Retrofit Kits
Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Why Use LED Retrofit Kits
LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.
LED Retrofit Kits for Open Air Parking Garage
LED Retrofit Kits for Traditional Wall Pack
Specificaion Summary
Power (W)
280W
280W
280W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
33,501
33,685
33,869
Efficacy (lm/W)
124
124
125
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
10.63"x10.00"x2.91"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Latest Nichia Technology chips
1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
Real Mean Well driver
One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.
Sunon Fan Technology
1. Unique design with fan (fans) inside, more uniform structure.
2. Smaller size, almost zero noise.
3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.
New Patented heat sink design
1. Adopting AL6063 material of high structural intensity.
2. Lower profile heat sink design, more slim.
3. Flat outer surface on the heat sink, more elegant.
Installation Process
How to install the DLC ETL cETL 200w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Application
The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture… -
Read More
320W LED Retrofit Kits320W LED Retrofit Kits
Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Why Use LED Retrofit Kits
LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.
LED Retrofit Kits for Open Air Parking Garage
LED Retrofit Kits for Traditional Wall Pack
Specificaion Summary
Power (W)
320W
320W
320W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
37,944
37,944
37,944
Efficacy (lm/W)
124
124
124
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
10.63"x10.00"x2.91"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Latest Nichia Technology chips
1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
Real Mean Well driver
One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.
Sunon Fan Technology
1. Unique design with fan (fans) inside, more uniform structure.
2. Smaller size, almost zero noise.
3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.
New Patented heat sink design
1. Adopting AL6063 material of high structural intensity.
2. Lower profile heat sink design, more slim.
3. Flat outer surface on the heat sink, more elegant.
Installation Process
How to install the DLC ETL cETL 200w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Application
The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture… -
Read More
350W LED Retrofit Kits350W LED Retrofit Kits
Product Description
KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
With various mounting brackets, the kits could retrofit a majority of fixtures whether it is a vertical or horizontal installation, eg: street light fixtures, shoebox fixtures, wall pack fixtures, flood light fixtures, canopy fixtures, and high bay fixtures, etc.
Specificaion Summary
Power (W)
350W
350W
350W
Color Temperature (CCT)
4000K
4500K
5000K
Lumen Output (LM)
42,321
41,971
43,514
Efficacy (lm/W)
121
120
125
Input Voltage (V)
100-277V
Power Factor
>93%
THD
<12%
CRI
73
Beam Angle (°)
120°
Installation
Horizontal / Vertical
Dimensions (in)
10.63"x10.00"x2.91"
LED Class
Nichia, UL Listed: LM80
Driver Class
Meanwell, UL Listed: Class II
Controls
Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature
-35°C to 55°C
Certifications
ETL/cETL, LM79, LM80
L70 Lifetime (hours)
≥200,000 hours
Warranty
10-year limited on LED head, 5-year limited on driver
Features
• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Optics
• Beam angle: 120° standard
Warranty
• 10-year limited on LED head, 5-year limited on driver
Mountings
• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket
Qaulity Control
IQC
1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.
IQC
1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
FQC
1. 100% appearance checking
2. 100% lable checking
3. 100% function checking
Mass Production
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation
