2835 LED Strips

  • Read More

    100lm/W 3D SMD2835-60-8mm-5m

    Feature / Warranty



    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.


    IP rate




    Electrical & Output Data





    Step length (mm/x LED)
    50mm/3LEDs
    100mm/6LEDs


    Number LED/m
    60
    60


    Voltage (v)
    12V
    24V


    Ra
    80 / 90 / 95
    80 / 90 / 95


    Beam Angle(º)
    120
    120


    Power (w/m)
    11.5
    11.52


    FPC width (mm)
    8
    8


    Max. length per circuit (m)
    5
    5


    IP rate
    20
    20


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    90lm/W @Ra80
    74.7lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    912m
     757lm


    2500K
     954lm
     783lm


    2700K
     995lm
     818lm


    3000K
     1037lm
     861lm


    3500K
     1058lm
     878m


    4000K
     1114lm
     924lm


    5000K
     1078lm
     921lm


    6000K
     1078lm
     921lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    100lm/W SMD2835-196-15mm-5m

    Feature / Warranty



    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.

    IP rate




    Aluminum Profiles


    Electrical & Output Data





    Step length (mm/x LED)
    71.4mm/7LEDs



    Number LED/m
    196



    Voltage (v)
    24V



    Ra
    80 / 90 / 95



    Beam Angle(º)
    120



    Power (w/m)
    20



    FPC width (mm)
    15



    Max. length per circuit (m)
    5



    IP rate
    20



    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    114lm/W @Ra80
    94.6lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    2006lm
     1665lm


    2500K
     2098lm
     1722lm


    2700K
     2189lm
     1789lm


    3000K
     2280lm
     1892lm


    3500K
     2326lm
     1930lm


    4000K
     1450lm
     2032lm


    5000K
     2371lm
     2025lm


    6000K
     2371lm
     2025lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    100lm/W SMD2835-182-10mm-5m

    Feature / Warranty



    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.


    IP rate




    Aluminum Profiles


    Electrical & Output Data





    Step length (mm/x LED)
    38.5mm/7LEDs



    Number LED/m
    182



    Voltage (v)
    24V



    Ra
    80 / 90 / 95



    Beam Angle(º)
    120



    Power (w/m)
    15



    FPC width (mm)
    10



    Max. length per circuit (m)
    5



    IP rate
    20/65



    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    115lm/W @Ra80
    95.5lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    1518lm
     1260lm


    2500K
     1587lm
     1303lm


    2700K
     1656lm
     1360lm


    3000K
     1725lm
     1432lm


    3500K
     1760lm
     1537lm


    4000K
     1854lm
     1537lm


    5000K
     1794lm
     1532lm


    6000K
     1794lm
     1532lm





    Dimensions & available lengths



    Illuminance Distribution



  • Read More

    100lm/W SMD2835-140-10mm-5m

    Feature / Warranty



    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.


    IP rate




    Aluminum Profiles


    Electrical & Output Data





    Step length (mm/x LED)
    50mm/7LEDs



    Number LED/m
    140



    Voltage (v)
    24V



    Ra
    80 / 90 / 95



    Beam Angle(º)
    120



    Power (w/m)
    14.4



    FPC width (mm)
    10



    Max. length per circuit (m)
    5



    IP rate
    20/65



    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    117lm/W @Ra80
    97.1lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    1483lm
     1231lm


    2500K
     1550lm
     1273lm


    2700K
     1671lm
     1328lm


    3000K
     1685lm
     1398lm


    3500K
     1718lm
     1426lm


    4000K
     1685lm
     1398lm


    5000K
     1752lm
     1496lm


    6000K
     1752lm
     1496lm





    Dimensions & available lengths



    Illuminance Distribution



  • Read More

    100lm/W SMD2835-140-6mm-2.5m

    Feature / Warranty





    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.


    IP rate




    Aluminum Profiles


    Electrical & Output Data





    Step length (mm/x LED)
    50mm/7LEDs



    Number LED/m
    140



    Voltage (v)
    12V



    Ra
    80 / 90 / 95



    Beam Angle(º)
    120



    Power (w/m)
    10.5



    FPC width (mm)
    6



    Max. length per circuit (m)
    2.5



    IP rate
    20



    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    117lm/W @Ra80
    97.1lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    1081lm
     897lm


    2500K
     1130lm
     928lm


    2700K
     1179lm
     969lm


    3000K
     1253lm
     1020lm


    3500K
     11253lm
     1040lm


    4000K
     1320lm
     1095lm


    5000K
     1278lm
     1091lm


    6000K
     1278lm
     1091lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    100lm/W SMD2835-120-10mm-5m

    Feature / Warranty







    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.




    IP rate





    Aluminum Profiles






        1616







            1708







                2308





    Electrical & Output Data





    Step length (mm/x LED)
    25mm/3LEDs
    50mm/5LEDs


    Number LED/m
    120
    120


    Voltage (v)
    12V
    24V


    Ra
    80 / 90 / 95
    80 / 90 / 95


    Beam Angle(º)
    120
    120


    Power (w/m)
    12.8
    12.8


    FPC width (mm)
    10
    10


    Max. length per circuit (m)
    5
    5


    IP rate
    20/65/66/67/68
    20/65/66/67/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    95lm/W @Ra80
    78.9lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    1070m
     888lm


    2500K
     1119lm
     918lm


    2700K
     1167lm
     431lm


    3000K
     547lm
     454lm


    3500K
     1240lm
     1029lm


    4000K
     1307lm
     1084lm


    5000K
     1265lm
     1080lm


    6000K
     1265lm
     1080lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    100lm/W SMD2835-72-10mm-5m

    Feature / Warranty



    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.


    IP rate



    Aluminum Profiles


    Electrical & Output Data





    Step length (mm/x LED)
    83.4mm/6LEDs



    Number LED/m
    72



    Voltage (v)
    24V



    Ra
    80 / 90 / 95



    Beam Angle(º)
    120



    Power (w/m)
    13.8



    FPC width (mm)
    10



    Max. length per circuit (m)
    5



    IP rate
    20/65/66/67/68



    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    90lm/W @Ra80
    74.7lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    1093lm
     907lm


    2500K
     1143lm
     938lm


    2700K
     1192lm
     979lm


    3000K
     1242lm
     1031lm


    3500K
     1267lm
     1051m


    4000K
     1335lm
     1103lm


    5000K
     1292lm
     1103lm


    6000K
     1292lm
     1103lm





    Dimensions & available lengths



    Illuminance Distribution





  • Read More

    100lm/W SMD2835-60-10mm-5m

    Feature / Warranty







    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.




    IP rate






    Aluminum Profiles






        1616









             1708







                2308






    Electrical & Output Data





    Step length (mm/x LED)
    50mm/3LEDs
    100mm/5LEDs


    Number LED/m
    60
    60


    Voltage (v)
    12V
    24V


    Ra
    80 / 90 / 95
    80 / 90 / 95


    Beam Angle(º)
    120
    120


    Power (w/m)
    5.76
    11.52


    FPC width (mm)
    10
    10


    Max. length per circuit (m)
    5
    5


    IP rate
    20/65/66/67/68
    20/65/66/67/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    90lm/W @Ra80
    74.7lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    912lm
     757lm


    2500K
     954lm
     783lm


    2700K
     995lm
     818lm


    3000K
     1037lm
     861lm


    3500K
     1058lm
     878m


    4000K
     1114lm
     924lm


    5000K
     1078lm
     921lm


    6000K
     1078lm
     921lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    100lm/W SMD2835-60-8mm-5m

    Feature / Warranty







    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.




    IP rate






    Aluminum Profiles






        1616









            1708







                2308






    Electrical & Output Data





    Step length (mm/x LED)
    50mm/3LEDs
    100mm/5LEDs


    Number LED/m
    60
    60


    Voltage (v)
    12V
    24V


    Ra
    80 / 90 / 95
    80 / 90 / 95


    Beam Angle(º)
    120
    120


    Power (w/m)
    5.76
    5.76


    FPC width (mm)
    8
    8


    Max. length per circuit (m)
    5
    5


    IP rate
    20/65/66/67/68
    20/65/66/67/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    95lm/W @Ra80
    78.9lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    482m
     400lm


    2500K
     503lm
     413lm


    2700K
     525lm
     431lm


    3000K
     547lm
     454lm


    3500K
     558lm
     463m


    4000K
     588lm
     488lm


    5000K
     569lm
     486lm


    6000K
     569lm
     486lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    100lm/W SMD2835-30-8mm-5m

    Feature / Warranty







    ◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
    ◆ High lumen output, popular with very high cost-effective.
    ◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
    ◆ UL/CE/ROHS certification.
    ◆ Warranty: 3 years.



    IP rate





    Aluminum Profiles







         1616









            1708







                2308






    Electrical & Output Data





    Step length (mm/x LED)
    100mm/3LEDs
    166.6mm/5LEDs


    Number LED/m
    30
    30


    Voltage (v)
    12V
    24V


    Ra
    80 / 90 / 95
    80 / 90 / 95


    Beam Angle(º)
    120
    120


    Power (w/m)
    5.76
    6.9


    FPC width (mm)
    8
    8


    Max. length per circuit (m)
    5
    5


    IP rate
    20/65/66/67/68
    20/65/66/67/68


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    90lm/W @Ra80
    74.7lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
    456lm
     379lm


    2500K
     477lm
     392lm


    2700K
     498lm
     409lm


    3000K
     518lm
     430lm


    3500K
     529lm
     439m


    4000K
     557lm
     462lm


    5000K
     539lm
     460lm


    6000K
     539lm
     460lm






    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    150lm/W SMD2835-480-40mm-2.5m

    Feature / Warranty



    ◆ We selected DC2.8-2.9V, 27-29LM, SMD2835 chips and adopted DC24V and 8 leds/group
    solution to design 150LM/W Led Strips.
    ◆ Sometimes customer want high brightness but compliant heat dissipation problem,
    150LM/W led strips could be a better choice.
    ◆ Adopt 1:2 OZ RA Copper PCB to reduce the voltage drop.
    ◆ We found that SMD2835 chips could get highest light efficiency when the drive current is 30ma.

    IP rate



    Aluminum Profiles


    Electrical & Output Data



    Step length (mm/x LED):50mm/24LEDs
    Number LED/m:480
    Voltage (v):24V
    Ra:80 / 90
    Beam Angle(º):120
    Power (w/m):40
    FPC width (mm):40
    Max. length per circuit (m):2.5
    IP rate:20
    Installation:3M Tape / Mounting Clips / Aluminum Profiles



    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    150lm/W @Ra80
    130lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
     4920lm
     4264lm


    2500K
     5160lm
     4472lm


    2700K
     5400lm
     4680lm


    3000K
     5580lm
     4836lm


    3500K
     5700lm
     4940lm


    4000K
     6000lm
     5200lm


    5000K
     60000lm
     5200lm


    6000K
     5820lm
     5044lm





    Dimensions & available lengths



    Illuminance Distribution
  • Read More

    150lm/W SMD2835-320-30mm-2.5m

    Feature / Warranty



    ◆ We selected DC2.8-2.9V, 27-29LM, SMD2835 chips and adopted DC24V and 8 leds/group
    solution to design 150LM/W Led Strips.
    ◆ Sometimes customer want high brightness but compliant heat dissipation problem,
    150LM/W led strips could be a better choice.
    ◆ Adopt 1:2 OZ RA Copper PCB to reduce the voltage drop.
    ◆ We found that SMD2835 chips could get highest light efficiency when the drive current is 30ma.

    IP rate



    Aluminum Profiles



    Electrical & Output Data



    Step length (mm/x LED):25mm/8LEDs
    Number LED/m:<320
    Voltage (v):24V
    Ra:80 / 90
    Beam Angle(º):120
    Power (w/m):33.3
    FPC width (mm) :30
    Max. length per circuit (m):2.5
    IP rate:20
    Installation:3M Tape / Mounting Clips / Aluminum Profiles



    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    150lm/W @Ra80
    130lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
     4096lm
     3550lm


    2500K
     4296lm
     3723lm


    2700K
     4496lm
     3896lm


    3000K
     4645lm
     4026lm


    3500K
     4745lm
     4113lm


    4000K
     4995lm
     4329lm


    5000K
     4995lm
     4329lm


    6000K
     4845lm
     4199lm





    Dimensions & available lengths



    Illuminance Distribution
