UFO LED High Bay Lights
-
Read More
UFO LED High Bay with Philips Xitanium DriverUFO LED High Bay with Philips Xitanium Driver
Product Description
Specifications:
Product name:
H003G UFO led high bay with Philips Xitanium driver
Power:
100W, 150W, 200W
Working voltage:
AC200-240V, 50Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
140-150LM/W
CONFIGURATIONS
LED chip:
Lumileds 3030 SMD
LED driver:
Philips Xitanium
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC, SAA, ETL, DLC
Applications:
Widely used in industrial areas, workshop, warehouse, supermarkets, store, toll station, etc.
Main Features :
Philips Xitanium driver is with high voltage output, and the efficiency is higher than other drivers in the markets;
Philips Xitanium driver has longer life, reached 100000 hours if working environment temperature is less than 40c degree.
Philips Xitanium driver can be used in areas with high temperature, up to 70c degree.
-
Read More
DLC SAA CE UFO led high bay H003FDLC SAA CE UFO led high bay H003F
Product Description
Specifications:
Product name:
UFO led high bay
Power:
60W, 80W, 100W, 120W, 150W, 200W, 240W
Working voltage:
AC100-277V, 50/60Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700K, 3000K
4000K, 5000K
5700K, 6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
140-150LM/W
Beam angle:
60, 90, 120degree for option
CONFIGURATIONS
LED chip:
Lumileds 3030 SMD
LED driver:
Mean Well, SOSEN, Philips Xitanium
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC, SAA, ETL, DLC
Applications:
Widely used in industrial areas, workshop, warehouse, supermarkets, store, toll station, etc.
-
Read More
Anti Glare 180lm per watt UFO LED High BayAnti Glare 180lm per watt UFO LED High Bay
Product Description
Specifications:
Product name:
H003G UFO led high bay
Power:
60W, 80W, 100W, 120W, 150W, 200W
Working voltage:
AC100-277V, 50/60Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700K, 3000K
4000K, 5000K
5700K, 6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
140-150LM/W; 170-180LM/W
Beam angle:
60, 90, 120degree for option
CONFIGURATIONS
LED chip:
Lumileds 3030 SMD
LED driver:
Mean Well, SOSEN, Philips Xitanium
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC, SAA, ETL, DLC
Applications:
Widely used in industrial areas, workshop, warehouse, supermarkets, store, toll station, etc.
3.ifferent models available with this desig -
Read More
170lm per watt 200w UFO led high bay light170lm per watt 200w UFO led high bay light
Product Description
Product name:
170lm/w 200w UFO led high bay lights
Power:
185W
Working voltage:
AC200-277V, 50/60Hz
PF:
> 0.97
TECHNICAL CHARACTERISTICS
Color:
Warm White
Natural White
Cool White
Color Temperature:
2700-3200K
4000-4500K
6000-6500K
CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
Lumens:
170LM/W
Beam angle:
60°, 90°, 120°
CONFIGURATIONS
LED chip:
3030 SMD(Lumileds)
LED driver:
Philips Xitanium
Heat sinks:
Aluminum
Body color:
Black, Grey
OTHERS
Operating Temperature:
-35℃ to 50℃
Operating Humidity:
10%-90% RH
Storage Temperature:
-35℃ to 60℃
Warranty:
5 Years
Certificates:
CE, RoHS, FCC, SAA -
Read More
UFO LED High Bay LightUFO LED High Bay Light
Product Description
Product Feature:
·Hollow heat sink design increase more airflow for better heat dissipation.
·LED and heat sink are parallel, no dark area, no shadow.
·Use CREE/Epistar LED provide 130lm/w.
·LED junction temperature less than 85℃.
·Lighter weight and smaller volume can help customer save freight cost.
·Motion sensor function available.
·1-10V Dimmable available.
·IP65 waterproof rating suitable for wet and damp location.
·Working environment in -30℃to 50℃.
·UL / ETL / DLC / CE / RoHS / LM79 / LM80 / IES file is available.
·50000 hours lifespan with 5 year warranty.
Product Specification:
Watt
60W
80W
100W
120W
150W
200W
240W
Total Lumens
7800LM
10400LM
13000LM
15600LM
19500LM
26000LM
31200LM
Beam Angle
60°/90°/120°
CCT
3000K-6000K
Input Voltage
AC100-277V, 50-60Hz
CRI
>80
Power Factor
>0.9
Operating Temperature
-35℃~55℃
IP Rating
IP65
Test Standard
IES/LM79/LM80
Safety Certification
UL / ETL / cETL /DLC/ CE / RoHS
Warranty Time
5 Years
Product Display:
Product Details:
Application:
LED UFO high bay fixtures are ideal for Warehouses, Manufacturing Facilities Gymnasi-ums, Aviation Hangars, Convention Centers, Big Box Retail Stores, Cold Storage Facilities. -
Read More
UFO LED High Bay Light-HBLUFO LED High Bay Light-HBL
Product Description
Product Feature:
●UGR<19 UFO high bay light,anti-dazzle and anti-glare design.
●Using CREE LED with high lumen efficiency reach to 130lm/w.
●Die-casting aluminum heat sink with excellent heat cooling.
●1-10V dimming and motion sensor are available.
●Tri-angle design on hook, fixed the lamp body more stable when the lamp hanging.
●IP65 waterproof for wet location.
●Working environment in -35℃ to 55℃.
●CE/RoHS certification.
●More than 50,000 hours lifespan with 5 years warranty.
Product Specification:
Item NO.
RMS-HB-60W
RMS-HB-100W
RMS-HB-150W
RMS-HB-200W
Watt
60W
100W
150W
200W
Total Lumens
7800LM
13000LM
19500LM
26000LM
Dimension
Φ220*134mm
Φ280*198mm
Φ320*207mm
Φ355*215mm
Beam Angle
120°
CCT
3000K-6000K
Input Voltage
AC100-277V, 50-60Hz
CRI
>80
Power Factor
>0.9
Operating Temperature
-35℃~55℃
IP Rating
IP65
Test Standard
IES/LM79/LM80
Safety Certification
CE / RoHS
Warranty Time
5 Years
Product Display:
Product Details:
Product Dimension:
Unit: mm
Application:
LED UFO high bay fixtures are ideal for Warehouses, Manufacturing Facilities Gymnasi-ums, Aviation Hangars, Convention Centers, Big Box Retail Stores, Cold Storage Facilities.
