LED Shoebox Retrofit Bulb

  • Read More

    65W LED Shoebox

    Product Description

    KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
    Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
    In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
    The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

    Specification Summary










     Power (W)
    65W
    65W
    65W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    7,200
    7,200
    7,837


    Efficacy (lm/W)
    120
    120
    126


    Input Voltage (V)
    100-277V, 347-480V available


    Power Factor
    >90%


    THD
    <20%


    CRI
    73


    Optics
    High Purity Anodized Aluminum Reflector


    Distribution
    Type III, Type V available


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Controls
    Photocell/Dimming/Motion sensors available


    Environment
    Wet Locations


    Operating Temperature
    –25°C to +45°C


    Certifications
    UL/cUL, LM79, LM80


    L70 Lifetime (hours)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty standard








    Features

    • High system efficacy up to 126 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Excellent thermal management ensures long lifespan
    • Tempered and shatter-resistant glass for durability
    • S316 stainless steel screws, stronger ability to resist corrosion
    • 10kA surge protection as standard
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%


    Controls
    • Surge protection
    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional



    Mounting Bracket

    • Slip Fitter Bracket
    • Trunnion Bracket
    • Slip Fitter Bracket
    • Yoko Bracket




    Housing & Finish

    • Die-casting aluminum heat sink
    • Tempered and shatter-resistant glass
    • High purity anodized Aluminum reflector
    • Bronze finish standard, black and white optional
    • RAL & custom colors available


    Compliance

    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available




    Optics

    • Type III
    • Type V


    Ratings

    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature Rated at –25°C to +45°C




    Electrical

    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming or 0-10V dimming


    Warranty

    • 6-year limited system warranty
    * Please refer to Green Inova’s warranty term for complete information.






    Advantages






    High Quality LED Chips

    1.Top brand high quality chips (L90>50,000hrs).
    2.Super high light efficacy.
    3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
    4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




    ADC 12 Die-cast Aluminium Heat Sink

    1. Die-cast aluminum gasketed enclosure.
    2. Protective powder coating for lasting appearance.
    3. All-in-one heatsink with perfect structure maximum heat dissipation.

    Lighting distribution

    Type III, Type V optional.






    Multifunctions

    1. 0-10V dimming optional
    2. Photocell sensor optional
    3. Dimming motion sensor optional
    4. Remote controller optional
    5. Surge protector (over current device) optional






    Mounting Brackets Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket






    Installation Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket










    Applications

    • Outdoor lighting
    • Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

    LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







    Projects that feedback from our customers

    Location: Mississippi, USA
    Product: 140W LED Shoebox Light



  • Read More

    105W LED Shoebox

    Product Description

    KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
    Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
    In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
    The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

    Specification Summary




     Power (W)
    105W
    105W
    65W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    11,600
    11,600
    11,600


    Efficacy (lm/W)
    121
    121
    121


    Input Voltage (V)
    100-277V, 347-480V available


    Power Factor
    >90%


    THD
    <20%


    CRI
    73


    Optics
    High Purity Anodized Aluminum Reflector


    Distribution
    Type III, Type V available


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Controls
    Photocell/Dimming/Motion sensors available


    Environment
    Wet Locations


    Operating Temperature
    –25°C to +45°C


    Certifications
    UL/cUL, LM79, LM80


    L70 Lifetime (hours)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty standard









    Features

    • High system efficacy up to 126 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Excellent thermal management ensures long lifespan
    • Tempered and shatter-resistant glass for durability
    • S316 stainless steel screws, stronger ability to resist corrosion
    • 10kA surge protection as standard
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%


    Controls
    • Surge protection
    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional



    Mounting Bracket

    • Slip Fitter Bracket
    • Trunnion Bracket
    • Slip Fitter Bracket
    • Yoko Bracket




    Housing & Finish

    • Die-casting aluminum heat sink
    • Tempered and shatter-resistant glass
    • High purity anodized Aluminum reflector
    • Bronze finish standard, black and white optional
    • RAL & custom colors available


    Compliance

    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available




    Optics

    • Type III
    • Type V


    Ratings

    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature Rated at –25°C to +45°C




    Electrical

    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming or 0-10V dimming


    Warranty

    • 6-year limited system warranty
    * Please refer to Green Inova’s warranty term for complete information.






    Advantages






    High Quality LED Chips

    1.Top brand high quality chips (L90>50,000hrs).
    2.Super high light efficacy.
    3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
    4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




    ADC 12 Die-cast Aluminium Heat Sink

    1. Die-cast aluminum gasketed enclosure.
    2. Protective powder coating for lasting appearance.
    3. All-in-one heatsink with perfect structure maximum heat dissipation.

    Lighting distribution

    Type III, Type V optional.






    Multifunctions

    1. 0-10V dimming optional
    2. Photocell sensor optional
    3. Dimming motion sensor optional
    4. Remote controller optional
    5. Surge protector (over current device) optional






    Mounting Brackets Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket






    Installation Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket










    Applications

    • Outdoor lighting
    • Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

    LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







    Projects that feedback from our customers

    Location: Mississippi, USA
    Product: 140W LED Shoebox Light



  • Read More

    140W LED Shoebox

    Product Description

    KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
    Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
    In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
    The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

    Specification Summary




     Power (W)
    140W
    140W
    140W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    16,000
    16,000
    16,000


    Efficacy (lm/W)
    123
    123
    123


    Input Voltage (V)
    100-277V, 347-480V available


    Power Factor
    >90%


    THD
    <20%


    CRI
    73


    Optics
    High Purity Anodized Aluminum Reflector


    Distribution
    Type III, Type V available


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Controls
    Photocell/Dimming/Motion sensors available


    Environment
    Wet Locations


    Operating Temperature
    –25°C to +45°C


    Certifications
    UL/cUL, LM79, LM80


    L70 Lifetime (hours)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty standard









    Features

    • High system efficacy up to 126 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Excellent thermal management ensures long lifespan
    • Tempered and shatter-resistant glass for durability
    • S316 stainless steel screws, stronger ability to resist corrosion
    • 10kA surge protection as standard
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%


    Controls
    • Surge protection
    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional



    Mounting Bracket

    • Slip Fitter Bracket
    • Trunnion Bracket
    • Slip Fitter Bracket
    • Yoko Bracket




    Housing & Finish

    • Die-casting aluminum heat sink
    • Tempered and shatter-resistant glass
    • High purity anodized Aluminum reflector
    • Bronze finish standard, black and white optional
    • RAL & custom colors available


    Compliance

    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available




    Optics

    • Type III
    • Type V


    Ratings

    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature Rated at –25°C to +45°C




    Electrical

    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming or 0-10V dimming


    Warranty

    • 6-year limited system warranty
    * Please refer to Green Inova’s warranty term for complete information.






    Advantages






    High Quality LED Chips

    1.Top brand high quality chips (L90>50,000hrs).
    2.Super high light efficacy.
    3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
    4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




    ADC 12 Die-cast Aluminium Heat Sink

    1. Die-cast aluminum gasketed enclosure.
    2. Protective powder coating for lasting appearance.
    3. All-in-one heatsink with perfect structure maximum heat dissipation.

    Lighting distribution

    Type III, Type V optional.






    Multifunctions

    1. 0-10V dimming optional
    2. Photocell sensor optional
    3. Dimming motion sensor optional
    4. Remote controller optional
    5. Surge protector (over current device) optional






    Mounting Brackets Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket






    Installation Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket










    Applications

    • Outdoor lighting
    • Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

    LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







    Projects that feedback from our customers

    Location: Mississippi, USA
    Product: 140W LED Shoebox Light



  • Read More

    210W LED Shoebox

    Product Description

    KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
    Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
    In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
    The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

    Specification Summary




     Power (W)
    210W
    210W
    210W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    25,300
    25,300
    25,300


    Efficacy (lm/W)
    120
    120
    120


    Input Voltage (V)
    100-277V, 347-480V available


    Power Factor
    >90%


    THD
    <20%


    CRI
    73


    Optics
    High Purity Anodized Aluminum Reflector


    Distribution
    Type III, Type V available


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Controls
    Photocell/Dimming/Motion sensors available


    Environment
    Wet Locations


    Operating Temperature
    –25°C to +45°C


    Certifications
    UL/cUL, LM79, LM80


    L70 Lifetime (hours)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty standard









    Features

    • High system efficacy up to 126 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Excellent thermal management ensures long lifespan
    • Tempered and shatter-resistant glass for durability
    • S316 stainless steel screws, stronger ability to resist corrosion
    • 10kA surge protection as standard
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%


    Controls
    • Surge protection
    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional



    Mounting Bracket

    • Slip Fitter Bracket
    • Trunnion Bracket
    • Slip Fitter Bracket
    • Yoko Bracket




    Housing & Finish

    • Die-casting aluminum heat sink
    • Tempered and shatter-resistant glass
    • High purity anodized Aluminum reflector
    • Bronze finish standard, black and white optional
    • RAL & custom colors available


    Compliance

    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available




    Optics

    • Type III
    • Type V


    Ratings

    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature Rated at –25°C to +45°C




    Electrical

    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming or 0-10V dimming


    Warranty

    • 6-year limited system warranty
    * Please refer to Green Inova’s warranty term for complete information.






    Advantages






    High Quality LED Chips

    1.Top brand high quality chips (L90>50,000hrs).
    2.Super high light efficacy.
    3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
    4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




    ADC 12 Die-cast Aluminium Heat Sink

    1. Die-cast aluminum gasketed enclosure.
    2. Protective powder coating for lasting appearance.
    3. All-in-one heatsink with perfect structure maximum heat dissipation.

    Lighting distribution

    Type III, Type V optional.






    Multifunctions

    1. 0-10V dimming optional
    2. Photocell sensor optional
    3. Dimming motion sensor optional
    4. Remote controller optional
    5. Surge protector (over current device) optional






    Mounting Brackets Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket






    Installation Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket










    Applications

    • Outdoor lighting
    • Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

    LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







    Projects that feedback from our customers

    Location: Mississippi, USA
    Product: 140W LED Shoebox Light



  • Read More

    300W LED Shoebox

    Product Description

    KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
    Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
    In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
    The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

    Specification Summary










     Power (W)
    300W
    300W
    300W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    35,000
    35,000
    35,000


    Efficacy (lm/W)
    121
    121
    121


    Input Voltage (V)
    100-277V, 347-480V available


    Power Factor
    >90%


    THD
    <20%


    CRI
    73


    Optics
    High Purity Anodized Aluminum Reflector


    Distribution
    Type III, Type V available


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Controls
    Photocell/Dimming/Motion sensors available


    Environment
    Wet Locations


    Operating Temperature
    –25°C to +45°C


    Certifications
    UL/cUL, LM79, LM80


    L70 Lifetime (hours)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty standard









    Features

    • High system efficacy up to 126 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Excellent thermal management ensures long lifespan
    • Tempered and shatter-resistant glass for durability
    • S316 stainless steel screws, stronger ability to resist corrosion
    • 10kA surge protection as standard
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%


    Controls
    • Surge protection
    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional



    Mounting Bracket

    • Slip Fitter Bracket
    • Trunnion Bracket
    • Slip Fitter Bracket
    • Yoko Bracket




    Housing & Finish

    • Die-casting aluminum heat sink
    • Tempered and shatter-resistant glass
    • High purity anodized Aluminum reflector
    • Bronze finish standard, black and white optional
    • RAL & custom colors available


    Compliance

    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available




    Optics

    • Type III
    • Type V


    Ratings

    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature Rated at –25°C to +45°C




    Electrical

    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming or 0-10V dimming


    Warranty

    • 6-year limited system warranty
    * Please refer to Green Inova’s warranty term for complete information.






    Advantages






    High Quality LED Chips

    1.Top brand high quality chips (L90>50,000hrs).
    2.Super high light efficacy.
    3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
    4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




    ADC 12 Die-cast Aluminium Heat Sink

    1. Die-cast aluminum gasketed enclosure.
    2. Protective powder coating for lasting appearance.
    3. All-in-one heatsink with perfect structure maximum heat dissipation.

    Lighting distribution

    Type III, Type V optional.






    Multifunctions

    1. 0-10V dimming optional
    2. Photocell sensor optional
    3. Dimming motion sensor optional
    4. Remote controller optional
    5. Surge protector (over current device) optional






    Mounting Brackets Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket






    Installation Options












    Slip Fitter


    Straight Arm


    Trunnion Bracket


    Yoko Bracket










    Applications

    • Outdoor lighting
    • Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

    LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







    Projects that feedback from our customers

    Location: Mississippi, USA
    Product: 140W LED Shoebox Light



  • Read More

    LED Shoebox Retrofit Bulb

    75W/100W perfect replacement lamp, widely used for shoebox, flood light, street light these totally enclosed fixtures. Internal driver without Fan design with 5 years warranty. E39/EX39/E40 base, the lighting angle is adjustable 180°/270°according to the applications. The lamp is high brightness with 150lm/w, LM80 standard LED. The whole series are UL DLC certificated. IES files are available.
