LED Canopy Lights

  • Read More

    20W LED Garage Lights High Output Canopy Light Sidewalls Lighting

    Product Description


    KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
    In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.



    Specification Summary










     Power (W)
    20W
    20W
    20W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    2,698
    2,698
    2,698


    Efficacy (lm/W)
    137
    137
    137


    Voltage (V)
    100-277V


    Power Factor
    >90%


    THD
    <20%


    CRI
    ≥73


    Optics
    UV resistant high quality lens


    Beam Angle (°)
    160° Std. ( 120° available)


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Operating Temperature(°C)
    –25°C to 45°C


    IP Rating
    IP65


    Environment
    Indoor or Outdoor


    Certificates
    UL cUL, LM79, LM80


    Controls
    10KA Surge Protection, Dimming, Sensors, Emergency back-up available


    Life (L70, H)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty












    Features



    • High system efficacy up to 142 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Optimized thermal design, separating driver from heat sink
    • Excellent thermal management ensures long lifespan
    • UV resistant high quality lens
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%



    Controls

    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional
    • Emergency back-up optional
    • Surge protection optional





    Electrical



    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming and 0-10V dimming





    Housing & Finish



    • Die-casting aluminum heat sink
    • Bronze finish standard, black and white optional
    • RAL & custom colors available








    Ratings



    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature rated at –25°C to +45°C





    Compliance



    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available






    Warranty



    • 6-year limited system warranty




    Beam Angle



    120°, 160° optional, UV resistant high quality lens. (Default 160°)












    Installation Options



    Ceiling mount, pendant mount and quick plate mount available.








    Quick Plate Mount









    Pendant Mount









    Ceiling Mount






    Advantages of Gen.6 Canopy Light

    • Unique design with elegant apperance
    • Optimized thermal design features excellent heat disspation
    • Unique optical lens, distributing light more uniformly on the ground
    • Easy installation: hand free for wiring connection, quick maintenance
    • Mounting: quick plate mount, ceiling mount, pendant mount
    • Sensor: microwave sensor (compatible with remote controller), photocell
    • Petents Pending: PCT patents, US patents, China patents



    Applications



    • Indoor & outdoor lighting
    • Underground packing lot, gas station, entry way, warehouse, etc



    High Output Canopy Lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.




  • Read More

    30W LED Gas Station Light Waterproof Canopy Light Underground Light 140lm/w

    Product Description


    KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
    In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.



    Specification Summary










     Power (W)
    30W
    30W
    30W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    3,737
    3,737
    3,737


    Efficacy (lm/W)
    137
    137
    137


    Voltage (V)
    100-277V (347-480V available)


    Power Factor
    >90%


    THD
    <20%


    CRI
    ≥73


    Optics
    UV resistant high quality lens


    Beam Angle (°)
    160° Std. ( 120° available)


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Operating Temperature(°C)
    –25°C to 45°C


    IP Rating
    IP65


    Environment
    Indoor or Outdoor


    Certificates
    UL cUL, LM79, LM80


    Controls
    10KA Surge Protection, Dimming, Sensors, Emergency back-up available


    Life (L70, H)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty











    Features



    • High system efficacy up to 142 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Optimized thermal design, separating driver from heat sink
    • Excellent thermal management ensures long lifespan
    • UV resistant high quality lens
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%



    Controls

    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional
    • Emergency back-up optional
    • Surge protection optional





    Electrical



    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming and 0-10V dimming





    Housing & Finish



    • Die-casting aluminum heat sink
    • Bronze finish standard, black and white optional
    • RAL & custom colors available








    Ratings



    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature rated at –25°C to +45°C





    Compliance



    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available






    Warranty



    • 6-year limited system warranty




    Beam Angle



    120°, 160° optional, UV resistant high quality lens. (Default 160°)












    Installation Options



    Ceiling mount, pendant mount and quick plate mount available.








    Quick Plate Mount









    Pendant Mount









    Ceiling Mount






    Advantages of Gen.6 Canopy Light

    • Unique design with elegant apperance
    • Optimized thermal design features excellent heat disspation
    • Unique optical lens, distributing light more uniformly on the ground
    • Easy installation: hand free for wiring connection, quick maintenance
    • Mounting: quick plate mount, ceiling mount, pendant mount
    • Sensor: microwave sensor (compatible with remote controller), photocell
    • Petents Pending: PCT patents, US patents, China patents



    Applications



    • Indoor & outdoor lighting
    • Underground packing lot, gas station, entry way, warehouse, etc



    Waterproof Canopy Lights  is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.




  • Read More

    40W LED Canopy Light Garage Light High Output Gas Station Light IP65 140lm/w

    Product Description


    KAIWIMs 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
    In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.



    Specification Summary










     Power (W)
    40W
    40W
    40W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    5,021
    5,021
    5,021


    Efficacy (lm/W)
    136
    136
    136


    Voltage (V)
    100-277V (347-480V available)


    Power Factor
    >90%


    THD
    <20%


    CRI
    ≥73


    Optics
    UV resistant high quality lens


    Beam Angle (°)
    160° Std. ( 120° available)


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Operating Temperature(°C)
    –25°C to 45°C


    IP Rating
    IP65


    Environment
    Indoor or Outdoor


    Certificates
    UL cUL, LM79, LM80


    Controls
    10KA Surge Protection, Dimming, Sensors, Emergency back-up available


    Life (L70, H)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty











    Features



    • High system efficacy up to 142 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Optimized thermal design, separating driver from heat sink
    • Excellent thermal management ensures long lifespan
    • UV resistant high quality lens
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%



    Controls

    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional
    • Emergency back-up optional
    • Surge protection optional





    Electrical



    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming and 0-10V dimming





    Housing & Finish



    • Die-casting aluminum heat sink
    • Bronze finish standard, black and white optional
    • RAL & custom colors available








    Ratings



    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature rated at –25°C to +45°C





    Compliance



    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available






    Warranty



    • 6-year limited system warranty




    Beam Angle



    120°, 160° optional, UV resistant high quality lens. (Default 160°)












    Installation Options



    Ceiling mount, pendant mount and quick plate mount available.








    Quick Plate Mount









    Pendant Mount









    Ceiling Mount






    Advantages of Gen.6 Canopy Light

    • Unique design with elegant apperance
    • Optimized thermal design features excellent heat disspation
    • Unique optical lens, distributing light more uniformly on the ground
    • Easy installation: hand free for wiring connection, quick maintenance
    • Mounting: quick plate mount, ceiling mount, pendant mount
    • Sensor: microwave sensor (compatible with remote controller), photocell
    • Petents Pending: PCT patents, US patents, China patents



    Applications



    • Indoor & outdoor lighting
    • Underground packing lot, gas station, entry way, warehouse, etc



    High Output Gas Station Light is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.




  • Read More

    55W LED Canopy Fixture High Output Garage lights Entryway Lighting

    Product Description


    KAIWIM 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
    In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.




    Specification Summary










     Power (W)
    55W
    55W
    55W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    7,165
    7,165
    7,165


    Efficacy (lm/W)
    139
    139
    139


    Voltage (V)
    100-277V (347-480V available)


    Power Factor
    >90%


    THD
    <20%


    CRI
    ≥73


    Optics
    UV resistant high quality lens


    Beam Angle (°)
    160° Std. ( 120° available)


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Operating Temperature(°C)
    –25°C to 45°C


    IP Rating
    IP65


    Environment
    Indoor or Outdoor


    Certificates
    UL cUL, LM79, LM80


    Controls
    10KA Surge Protection, Dimming, Sensors, Emergency back-up available


    Life (L70, H)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty












    Features



    • High system efficacy up to 142 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Optimized thermal design, separating driver from heat sink
    • Excellent thermal management ensures long lifespan
    • UV resistant high quality lens
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%



    Controls

    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional
    • Emergency back-up optional
    • Surge protection optional





    Electrical



    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming and 0-10V dimming





    Housing & Finish



    • Die-casting aluminum heat sink
    • Bronze finish standard, black and white optional
    • RAL & custom colors available








    Ratings



    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature rated at –25°C to +45°C





    Compliance



    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available






    Warranty



    • 6-year limited system warranty




    Beam Angle



    120°, 160° optional, UV resistant high quality lens. (Default 160°)












    Installation Options



    Ceiling mount, pendant mount and quick plate mount available.








    Quick Plate Mount









    Pendant Mount









    Ceiling Mount






    Advantages of Gen.6 Canopy Light

    • Unique design with elegant apperance
    • Optimized thermal design features excellent heat disspation
    • Unique optical lens, distributing light more uniformly on the ground
    • Easy installation: hand free for wiring connection, quick maintenance
    • Mounting: quick plate mount, ceiling mount, pendant mount
    • Sensor: microwave sensor (compatible with remote controller), photocell
    • Petents Pending: PCT patents, US patents, China patents



    Applications



    • Indoor & outdoor lighting
    • Underground packing lot, gas station, entry way, warehouse, etc



    High Output Garage lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.




  • Read More

    80W LED Garage Light Fixtures LED Canopy Light Waterproof Outdoor Ceiling Lights

    Product Description


    KAIWIM 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
    In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.




    Specification Summary












     Power (W)
    80W
    80W
    80W


    Color Temperature (CCT)
    4000K
    4500K
    5000K


    Lumen Output (LM)
    10,039
    10,039
    10,039


    Efficacy (lm/W)
    133
    133
    133


    Voltage (V)
    100-277V (347-480V available)


    Power Factor
    >90%


    THD
    <20%


    CRI
    ≥73


    Optics
    UV resistant high quality lens


    Beam Angle (°)
    160° Std. ( 120° available)


    LED Class
    UL Listed: LM80


    Driver Class
    UL Listed: Class II


    Operating Temperature(°C)
    –25°C to 45°C


    IP Rating
    IP65


    Environment
    Indoor or Outdoor


    Certificates
    UL cUL, LM79, LM80


    Controls
    10KA Surge Protection, Dimming, Sensors, Emergency back-up available


    Life (L70, H)
    150,000 hours per L70 TM-21@ 25°C


    Warranty
    6-year limited system warranty














    Features



    • High system efficacy up to 142 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Optimized thermal design, separating driver from heat sink
    • Excellent thermal management ensures long lifespan
    • UV resistant high quality lens
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%



    Controls

    • High system efficacy up to 142 LPW
    • Class II UL listed driver
    • Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
    • Optimized thermal design, separating driver from heat sink
    • Excellent thermal management ensures long lifespan
    • UV resistant high quality lens
    • Various mounting brackets for different applications
    • Environmentally friendly surface finish
    • Multiple optics allowing flexible designs
    • Various controls to achieve high energy saving
    • Reduces energy consumption over 70%





    Electrical



    • 100-277V, and 347-480V available
    • System power factor >90% and THD <20%
    • LED driver with non-dimming and 0-10V dimming




    Ratings



    • 150,000 hours per L70 TM-21@ 25°C
    • Temperature rated at –25°C to +45°C



    • 0-10V dimming optional
    • Photocell sensor optional
    • Dimming motion sensor optional
    • Remote controller optional
    • Emergency back-up optional
    • Surge protection optional






    Housing & Finish



    • Die-casting aluminum heat sink
    • Bronze finish standard, black and white optional
    • RAL & custom colors available




    Compliance



    • DLC Premium
    • UL/cUL listed
    • UL 1598 suitable for wet locations
    • LM79, LM80 test reports
    • CE & RoHS available






    Warranty



    • 6-year limited system warranty




    Beam Angle



    120°, 160° optional, UV resistant high quality lens. (Default 160°)












    Installation Options



    Ceiling mount, pendant mount and quick plate mount available.








    Quick Plate Mount









    Pendant Mount









    Ceiling Mount






    Advantages of Gen.6 Canopy Light



    • Unique design with elegant apperance
    • Optimized thermal design features excellent heat disspation
    • Unique optical lens, distributing light more uniformly on the ground
    • Easy installation: hand free for wiring connection, quick maintenance
    • Mounting: quick plate mount, ceiling mount, pendant mount
    • Sensor: microwave sensor (compatible with remote controller), photocell
    • Petents Pending: PCT patents, US patents, China patents



    Applications



    • Indoor & outdoor lighting
    • Underground packing lot, gas station, entry way, warehouse, etc



    High Output Garage lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.




  • Read More

    80w explosion proof led lighting for gas station

    Product Description

    Product Name: 80w explosion proof LED lighting for gas station

    With Philips LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    80w Explosion proof led lighting




    Power:


    80W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    96pcs Philips LED




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    4.5 KGS



    Gross Weight:

    5.5 KGS



    Packing Size:

    40*40*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 80w explosion proof led lighting:


    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
  • Read More

    120w LED Gas Station canopy lights

    Product Description

    Product Name: 120w LED gas station canopy lights

    With Philips LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    120w LED gas station canopy lights




    Power:


    120W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    144pcs Philips LED




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    5.5 KGS



    Gross Weight:

    6.5 KGS



    Packing Size:

    40*40*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 120w LED gas station canopy lights:


    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
  • Read More

    150w explosion proof LED canopy lights

    Product Description

    Product Name: 150w Explosion Proof LED canopy lights

    With Philips LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    150w explosion proof led canopy lights




    Power:


    150W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    192pcs Philips LED




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    7.0 KGS



    Gross Weight:

    8.5 KGS



    Packing Size:

    40*50*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 150w explosion proof LED canopy lights:


    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
  • Read More

    200w LED gas station lighting

    Product Description

    Product Name: 200w Explosion Proof LED gas station lighting

    With Philips LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    200w Explosion Proof LED gas station lighting




    Power:


    200W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    240pcs Philips LED




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    8.5 KGS



    Gross Weight:

    10.5 KGS



    Packing Size:

    40*63*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 200w explosion proof LED gas station lighting:


    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
  • Read More

    80watts Explosion Proof LED lights with CREE

    Product Description

    Product Name: 80watts explosion proof LED lights for gas station

    With CREE LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    80watts explosion proof led lights




    Power:


    80W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    48pcs CREE XTE




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    4.5 KGS



    Gross Weight:

    5.5 KGS



    Packing Size:

    40*40*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 80watts explosion proof led lights:


    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
  • Read More

    120w LED canopy lights for gas station with CREE

    Product Description

    Product Name: 120w LED canopy lights for gas station

    With CREE LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    120w LED canopy lights for gas station




    Power:


    120W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    72pcs CREE XTE




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    5.5 KGS



    Gross Weight:

    6.5 KGS



    Packing Size:

    40*40*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 120w LED canopy lights for gas station:



    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
  • Read More

    150w explosion proof led lamps with CREE

    Product Description

    Product Name: 150w Explosion Proof LED lamps for gas station

    With CREE LED, Mean Well driver, 5 years warranty

    Specifications:





    Product name:


    150w explosion proof led lamps




    Power:


    150W




    Working voltage:


    AC90-295V, 50/60Hz




    PF:


    > 0.97




    TECHNICAL CHARACTERISTICS




    Color:


    Warm White


    Natural White


    Cool White




    Color Temperature:


    2700-3200K


    4000-4500K


    6000-6500K




    CRI:


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra


    >70Ra, can be over 80Ra




    Lumens:

    115-120LM/W



    CONFIGURATIONS




    LED chip:


    96pcs CREE XTE




    LED driver:


    Mean Well




    Heat sinks:


    Aluminum




    Body color:


    White




    OTHERS




    Operating Temperature:


    -35℃  to  50℃




    Operating Humidity:


    10%-90%  RH




    Storage Temperature:


    -35℃  to  60℃




    Net Weight:

    7.0 KGS



    Gross Weight:

    8.5 KGS



    Packing Size:

    40*50*20CM



    Warranty:


    5 Years




    Certificates:


    CE, RoHS, FCC





    Product Size of 150w explosion proof LED lamps:


    Application:

    Gas station, shop, warehouse, indoor sports stadium with ceiling, etc.
