Product Description

KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to  LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.

Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood  light boxes, Area Light, high-bay and Street light applications.

Why Use LED Retrofit Kits

LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.

LED Retrofit Kits for Open Air Parking Garage


LED-RETROFIT-KITS-FOR-PARKING-LOTS

LED Retrofit Kits for Traditional Wall Pack


LED-RETROFIT-KITS-FOR-WALL-PACK


Specificaion Summary

 Power (W) 280W 280W 280W
Color Temperature (CCT) 4000K 4500K 5000K
Lumen Output (LM) 33,501 33,685 33,869
Efficacy (lm/W) 124 124 125
Input Voltage (V) 100-277V
Power Factor >93%
THD <12%
CRI 73
Beam Angle (°) 120°
 Installation Horizontal / Vertical
Dimensions (in) 10.63"x10.00"x2.91"
LED Class Nichia, UL Listed: LM80
Driver Class Meanwell, UL Listed: Class II
Controls Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature -35°C to 55°C
Certifications ETL/cETL, LM79, LM80
L70 Lifetime (hours) ≥200,000 hours
Warranty 10-year limited on LED head, 5-year limited on driver


Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Optics

• Beam angle: 120° standard

Warranty

• 10-year limited on LED head, 5-year limited on driver

Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket


Nichia LED

Latest Nichia Technology chips

1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.

2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.

Real Mean Well driver

One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.

Meanwell-driver
Sunon-fan

Sunon Fan Technology

1. Unique design with fan (fans) inside, more uniform structure.

2. Smaller size, almost zero noise.

3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.

New Patented heat sink design

1. Adopting AL6063 material of high structural intensity.

2. Lower profile heat sink design, more slim.

3. Flat outer surface on the heat sink, more elegant.

LED-retrofit-kits-patent-design

Installation Process

How to install the DLC ETL cETL 200w LED retrofit into the traditional fixtures?

All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.

Application

The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture…


LED-retrofit-kits-application
LED-RETROFIT-KITS-INSTALLATION-PHOTOS-A
