Product Description
Product Name: SMD LED warehouse light 80w



Product name:
SMD led warehouse light 80w


Power:
80W


Working voltage:
AC90-305V, 50/60Hz; 180-277V


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-4500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
140LM/W


Beam Angle:
30°， 60°，90°, 120°


IP Rate:
IP54


CONFIGURATIONS


LED chip:
154PCS 3030 smd led(OSRAM, Lumileds, Epistar)


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
White, Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%Rh


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
CE, RoHS, FCC, ETL, SAA





Applications:
Widely used for warehouse, workshop, exhibition hall, supermarkets, library, toll station, etc;
Different beam angles are available: 30° , 45°, 60°, 90°, 120°;
With a reflector, the UGR can be much lower, less shining;
Both aluminum reflector and PC reflectors are available.


Product Description
Product Name: Low UGR 100 watt LED highbay lighting



Product name:
Low UGR 100 watt led highbay lighting


Power:
100W


Working voltage:
AC90-305V, 50/60Hz; 180-277V


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-4500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
140LM/W


Beam Angle:
30°， 60°，90°, 120°


IP Rate:
IP54


CONFIGURATIONS


LED chip:
154PCS 3030 smd led(OSRAM, Lumileds, Epistar)


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
White, Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%Rh


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
CE, RoHS, FCC, ETL, SAA





Applications:
Widely used for warehouse, workshop, exhibition hall, supermarkets, library, toll station, etc;
Different beam angles are available: 30° , 45°, 60°, 90°, 120°;
With a reflector, the UGR can be much lower, less shining;
Both aluminum reflector and PC reflectors are available.


Product Description
Product Name: 60 watt led low bay light



Product name:
60 watt led low bay light


Power:
60W


Working voltage:
AC90-240V, 50/60Hz; 180-277V


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-4500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
140LM/W


Beam Angle:
30°， 60°，90°, 120°


IP Rate:
IP54


CONFIGURATIONS


LED chip:
80PCS 3030 smd led(OSRAM, Lumileds, Epistar)


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
White, Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%Rh


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
CE, RoHS, FCC, ETL, SAA





Applications:
Widely used for warehouse, workshop, exhibition hall, supermarkets, library, toll station, etc;
Different beam angles are available: 30° , 45°, 60°, 90°, 120°;
With a reflector, the UGR can be much lower, less shining;
Both aluminum reflector and PC reflectors are available.


Product Description
Product Name: 150 watt LED high bay



Product name:
150 watt led high bay


Power:
150W


Working voltage:
AC90-305V, 50/60Hz; 180-277V


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-4500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
140LM/W


Beam Angle:
30°， 60°，90°, 120°


IP Rate:
IP54


CONFIGURATIONS


LED chip:
203PCS 3030 smd led(OSRAM, Lumileds, Epistar)


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
White, Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%Rh


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
CE, RoHS, FCC, ETL, SAA





Applications:
Widely used for warehouse, workshop, exhibition hall, supermarkets, library, toll station, etc.


Product Description
Product Name: 200w industrial led bells



Product name:
200w industrial led bells


Power:
200W


Working voltage:
AC90-305V, 50/60Hz; 180-277V


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-4500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
140LM/W


Beam Angle:
30°， 60°，90°, 120°


IP Rate:
IP54


CONFIGURATIONS


LED chip:
252PCS 3030 smd led(OSRAM, Lumileds, Epistar)


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
White, Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%Rh


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
CE, RoHS, FCC, ETL, SAA





Applications:
Widely used for warehouse, workshop, exhibition hall, supermarkets, library, toll station, etc.


Product Description
Product Name: Low UGR 240 watt high bay led lighting



Product name:
Low UGR 240 watt high bay led lighting


Power:
240W


Working voltage:
AC90-305V, 50/60Hz; 180-277V


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-4500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
140LM/W


Beam Angle:
30°， 60°，90°, 120°


IP Rate:
IP54


CONFIGURATIONS


LED chip:
252PCS 3030 smd led(OSRAM, Lumileds, Epistar)


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
White, Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%Rh


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
CE, RoHS, FCC, ETL, SAA




Applications:
Widely used for warehouse, workshop, exhibition hall, supermarkets, library, toll station, etc;
Different beam angles are available: 30° , 45°, 60°, 90°, 120°;
With a reflector, the UGR can be much lower, less shining;
Both aluminum reflector and PC reflectors are available.
