950W 1000W LED High Mast Light Luminaire High Power Flood Light

950W 1000W LED High Mast Light Luminaire High Power Flood Light

  • 產品浮水印-02.jpg
  • 產品浮水印-04.jpg
DETAIL

LED stadium light high mast lighting
LED stadium light Certifications

Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.



Specification Summary

 Power (W) 950W
Color Temperature (CCT) 3000K/4000K/5000K/5700K/6500K (others available)
Lumen Output (LM) 115,344
Efficacy (lm/W) 122
Input Voltage (V) 100-277V (347-480V available)
Power Factor >95%
CRI ≥70Ra, or ≥90Ra
Gross Weight 27 kgs / 59.5 lbs
Dimensions (in) Φ531mm  × L172mm
IP Rating IP67
IK Rating IK10 (High impact resistance)
Anti-wind Test Withstand class 17 typhoon
Beam Angle (°) 16°, 40°, 60°, 90°, Type III, Type V optional
Driver Brand Meanwell
LED Class UL Listed: LM80
Driver Class UL Listed: Class II
SPD 20KV or 40KV
Photocontrol Twist-lock photocell available
Dimming Options 0-10V dimming / Zigbee wireless dimming available
Zigbee Control On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)
DMX Control DMX512 control available
Environment Indoor or outdoor
Operating Temperature –40°C- 40°C / -40°F - 104°F
Certifications UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)
L70 Lifetime (hours) >100,000 Hrs (L70 @ 25°C)
Warranty 7-year warranty for 100-277V version, 5-year warranty for 347-480V version



Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.

● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.

Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..



Wattage   Beam Angle   NEMA Angle
  300W-500W 16° 3H3V
  300W-500W 40° 4H4V
  300W-500W 60° 5H5V
  300W-500W 90° 6H6V
  600W-750W 16° 3H3V
  600W-750W 40° 4H4V
  600W-750W 60° 5H5V
 950W-1200W 16° 3H3V
 950W-1200W 40° 4H4V
 950W-1200W 60° 5H5V

LED high mast light beam angle
LED stadium light beam angle

Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Mast Light Heat dissipation

High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


LED sports light high mast

Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Slim LED Stadium Lihgt

Dimensions

LED-stadium-light-300W-400W-500W-dimension 300W / 400W / 500W
LED-stadium-light-600W-750W-dimension 600W / 750W
LED-stadium-light-950W-1200W-dimension 950W / 1200W

Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.

LED-stadium-light-mounting Horizontal Mount
LED-stadium-light-mounting-2 Vertical Mount
LED-stadium-light-mounting-3 Ceiling Mount

Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

LED stadium light application

Application: Outdoor area high mast pole
Location: Saudi Arabia

LED stadium light application-golf-Green Inova

Application: Water Golf Course
Location: Vietnam
