KAIWIM led loading dock light is designed for a variety of warehouse and work space conditions, led loading bay dock lights used to illuminate the full length of truck trailers.
The set dock light fixtures increase safety during loading and unloading.
Product Feature:
·Optimum brightness for entire length of trailer.
·Built-in switch to control on-off.
·Adjustable screw on the lamp, adjust lamp's angle by hand.
·Eliminates light bulb replacement and/or clean-up.
·Compact design utilizes aluminum housing for cooling system.
·High-visibility beam angles for optional.
·Cree/Epistar LED is available.
·Over 50000 hours lifetime and offer 5 years warranty.
·ETL/cETL/CE/RoHS certificates.
Product Specification:
| Watt | 20W | 30W | 40W | 50W |
| Total Lumens | 2800LM | 4200LM | 5600LM | 7000LM |
| Dimension | Φ219*163*70mm | |||
| Beam Angle | 30° | |||
| Surge Voltage | 4KV | |||
| CCT | 3000K-6500K | |||
| Input Voltage | AC100-277V, 50-60Hz | |||
| CRI | >70+ | |||
| Power Factor | >0.9 | |||
| Operating Temperature | -40℃ to 60℃ | |||
| IP Rating | IP65 | |||
| Test Standard | IES/LM79/LM80 | |||
| Safety Certification | ETL / cETL / FCC / CE / RoHS | |||
| Warranty Time | 5 Years | |||
Product Details:
Product Dimension:
Application:
LED dock light is designed for industrial, manufacturing and warehousing, that is also a perfect LED replacement for traditional incandescent/HPS yellow fixture, illuminate tractor trailers for loading and unloading.
Applications include shipping and receiving loading docks, machine stations such as a stomping press, inspection stations, general work lighting, indoor and outdoor spot lighting, and other similar applications.
