High performance output, low profile KWRS-SPFL-03 led flood light utilizing Philips Lumileds LED and Meanwell driver, offering 100w~1200w for choice. High lumens can up to 150 lumen per watt, Available in 20°/40°/60°/90° multiple optical lenses for sports venuse and large areas
Product Feature:
* High reliable Meanwell driver and high bright Philips Luminleds LEDs;
* Multiple optical lenses are available to meet a variety of lighting needs.;
* High strength aluminium structure with excellent thermal management design;
* Corrosion resistant polyester powder coat finish;
* IP65 rating against dust,waterproof,weather for outdoor usage;
* Easy installation and maintenance,longer lifetime with high lumen maintenance;
* Energy savings, no UV and IR radiations, emits low heat;
* Ideal replacement to traditional metal halide lamp of 300W to 4000W;
* Intelligent dimming system:0-10V, DMX and DALI dimming modes are available;
* ETL/cETL/FCC/CE/RoHS/SAA/C-TICK approval
Product Specification:
| Watt | 100W | 200W | 300W | 400W | 500W | 600W | 700W | 800W | 1000W | 1200W |
| Total Lumens | 15000LM | 30000LM | 45000LM | 60000LM | 75000LM | 90000LM | 105000LM | 120000LM | 150000LM | 180000LM |
| Beam Angle | 20°/40°/60°/90° | |||||||||
| CCT | 2700K-6500K | |||||||||
| Input Voltage | 100-277Vac/200-480Vac, 50-60Hz | |||||||||
| LED Brand | Philips Luminleds | |||||||||
| CRI | >70 | |||||||||
| Power Factor | >0.9 | |||||||||
| Operating Temperature | -35℃~55℃ | |||||||||
| IP Rating | IP65 | |||||||||
| Test Standard | IES/LM79/LM80 | |||||||||
| Safety Certification | ETL / cETL / FCC / CE / RoHS / SAA / C-TICK / | |||||||||
| Warranty Time | 5 Years | |||||||||
Product Display:
Product Details:
Product Dimensions:
Application:
Applied in large sports field lighting, football, basketball, golf and tennis court, racetrack, badminton, roads, high-rise buildings, tower lights, etc.
Can also be applied in large square, airport, commercial building, construction engineering, farm, amusement parks, parking lots, harbor, industrial buildings, and other special lighting environment.
